Looking at the diagram below you can see connecting two wires from a simple push button to Row 1 and Column 1 would activate S1 (Button 1), Row 1 and Column 2 activates S2, Row 2 Column 1 activates S7 etc. We recommend ready-made matrix add-on board for easy matrix wiring.Ĭonnects to six ROWS and six COLUMNS pins on the controller. Pin header has standard 0.1" (2.54mm) pitch.ģ2 digital inputs for buttons and switches via wiring matrix Plug it in and use straight away.Įight 3-pin and two 6-pin connectors are included with each controller to solder your wires to (to save soldering directly to the pins on the PCB) or connect using our 3-pin and 2-pin cables. The PCB has a standard USB B type connector for connection to PC or Mac. M2.5 or #3-56 - DO NOT ENLARGE THE MOUNTING HOLES Inputs 8 analog inputs with 12-bit (4096 steps) resolution each A small USB joystick interface board with pin header connectors to connect buttons, potentiometers, sensors, rotary encoders and switches to a PC or Mac.īuild your own gaming device, whether it be a flight panel, button box, pedals, joystick, robot controls and more.the list is limited by your imagination.Īlso suitable for converting gameport devices or connecting real life controls to turn them into a USB device suitable to be used by almost any simulation or game software without the need of installing any drivers.
